ComPrehensIve daTa PoInT Tables
Network Control Property
Keypad attributes available as BACnet
Standard Objects for network control
of the unit Page R = Read W = Write Object Type Object Instance Description
Power Factor
Compressor Select
Compressor #2
Compressor #3
Compressor #4
Compressor #5
Compressor #6
84 R -99 – +100
AI 53
AI 78
AI 97
AI 105
AI 113
AI 119
Pump Select 85 W MSO 47 1=Pump No. 1, 2=Pump No. 2; Default=1
Run Enabled 86 R BI 33 0=OFF, 1=Run Allowed
*Boldface denotes data points for typical minimum integration.
Chiller Alarm Objects
Network Control Property
Keypad attributes available as BACnet Standard
Objects for network control of the unit Page R = Read W = Write Object Type Object Instance Description
Warning Alarms, Analog Input Object (11) 88 R AI 902 Alarm Index
Problem Alarms, Analog Input Object (11) 88 R AI 900 Alarm Index
Fault Alarms, Analog Input Object (11) 88 R AI 901 Alarm Index
Warning Alarms, Multi-state Input Object (11) 89 R MSI 902 Alarm Index and Alarm Text (30 characters max)
Problem Alarms, Multi-state Input Object (11) 89 R MSI 900 Alarm Index and Alarm Text (30 characters max)
Fault Alarms, Multi-state Input Object (11) 90 R MSI 901 Alarm Index and Alarm Text (30 characters max)
Alarm Digital Output (11) 90 R BI 40 0-No Alarm, 1=Alarm
BACnet Clear Alarm (12) 91 W BV 42 0= Normal, 1=Clear Alarm
