ComPrehensIve daTa PoInT Tables
Network Input Variables
Network Control Property
Keypad attributes available
as LONWORKS Variables for
network control of the unit
Variable Name Page
SNVT
Index
Description
*Capacity Limit Setpoint (10) nviCapacityLim 25 81 0 to 160%; Default=100%
*Chiller Enable (Input) (4) nviChillerEnable 26 95 0=Request Chiller OFF, 1=Request Chiller On; Default=OFF
Chiller Mode Setpoint nviMode 31 108
1=HVAC_HEAT, 3=HVAC_COOL, 5=HVAC_PRE_COOL, 11=HVAC_ICE;
Default=Cool
Compressor Select nviCompSelect 43 8 See Variable Description
*Cool Setpoint (9) nviCoolSetpt 58 105 -12.2– 48.8°C; Default=7.2°C
Heat Setpoint nviHeatSetpt 71 105 10–93°C; Default=35°C
Ice Setpoint nviIceSpt 72 105 -9.4– 1.7°C; Default=-3.9°C
*Network Clear Alarm (12) nviClearAlarm 97 95 0= Inactive,1=Clear Alarm; Default=0
Pump Select nviPumpSelect 85 95 0=Pump No. 1, 1=Pump No. 2; Default=0
*Boldface denotes data points for typical minimum integration.
Network Conguration Parameters
Network Control Property
Keypad attributes available as LONWORKS
Variables for network control of the unit Variable Name Page SCPT_Reference
SCPT
Index Description Default Value
Capacity Limit (LONWORKS Conguration) nciCapacityLim 24 SCPT_limitChlrCap 81 0% to 160%. 100%
Chiller Enable (LONWORKS Conguration) nciChillerEnable 27 SCPT_pwrUpState 73
0=Request Chiller OFF, 1=Request
Chiller Auto (run)
0
Cool Setpoint (LONWORKS Conguration) nciCoolSetpt 58 SCPT_CoolSetpoint 75 -40°C to 93°C 7.2°C
Default Values nciDefaults 59 SCPT_maxSendTime 71
0=Use Default Values, 1=Use
Manufacturer-Specied Values
0
Heat Setpoint (LONWORKS Conguration) nciHeatSetpt 71 SCPT_HeatSetpoint 78 -40–93°C 37.8°C
Chiller Location nciLocation 29 SCPT_location 17
Any NUL terminated ASCII string up to
31 bytes.
00000
Maximum Send Time nciMaxSendTime 76 SCPT_maxSendTime 52 0–6553.4 sec 0 sec
Minimum Send Time nciMinSendTime 77 SCPT_minSendTime 52 0–6553.4 sec 0 sec
*Chiller Mode (LONWORKS Conguration) (2) nciMode 29 SCPT_HVACmode 74
1=HVAC_HEAT, 3=HVAC_COOL,
11=HVAC_ICE
3
Receive Heartbeat nciRcvHrtBt 86 SCPT_maxRcvTime 49 0.0–6553.4 sec (0.1 sec) 0
*Boldface denotes data points for typical minimum integration.
