deTaIled daTa PoInT InformaTIon
www.DaikinApplied.com 43 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Compressor Select
Keypad Menu Path:
No Keypad Equivalent
This input network variable selects the compressor/circuit (number 1, 2, 3, 4, 5 or 6) that is interrogated.
The controller returns the information for the selected compressor/circuit. You must rst select a
compressor/circuit then interrogate the selected compressor/circuit. This variable selects a compressor/
circuit for the following variables. See Table 2 on page 21 (Data Points for Chiller Models) to
determine which of these variables will be available. (I32)
Name Page Name Page
Compressor Current 36 Evaporator Leaving Water Temperature for Compressor 57
Compressor Discharge Temperature 38 Evaporator Refrigerant Pressure 58
Compressor Percent RLA 39 Evaporator Saturated Refrigerant Temperature 59
Compressor Power 40 Liquid Line Refrigerant Pressure 63
Compressor Run Hours 41 Liquid Line Refrigerant Temperature 65
Compressor Starts 43 Oil Feed Pressure 67
Compressor Status 44 Oil Feed Temperature 68
Compressor Voltage 46 Oil Sump Pressure 69
Condenser Refrigerant Pressure 50 Oil Sump Temperature 69
Condenser Saturated Refrigerant Temperature 51
Measurement Units Data Type Valid Range Default Value
Event Count NA
BACnet: Unsigned Integer
LONWORKS: Fixed Point
Scalar - unsigned long
1–6 Comp No. 1
BACnet
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Multi-state Output 14 46 Present Value 85
Object Name
CompSelect
Property Values
1 = Comp/Circuit No. 1
2 = Comp/Circuit No. 2
3 = Comp/Circuit No. 3 (Circuit No. 1 on Scroll Chillers and Condensing Units)
4 = Comp/Circuit No. 4 (Circuit No. 2 on Scroll Chillers and Condensing Units)
5 = Comp No. 5 (Circuit No. 1 on Scroll Chillers and Condensing Units)
6 = Comp No. 6 (Circuit No. 2 on Scroll Chillers and Condensing Units)
LONWORKS
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size
nviCompSelect Proprietary count 8 two bytes
Valid Range
1 = Comp/Circuit No. 1
2 = Comp/Circuit No. 2
3 = Comp/Circuit No. 3 (Circuit No. 1 on Scroll Chillers and Condensing Units)
4 = Comp/Circuit No. 4 (Circuit No. 2 on Scroll Chillers and Condensing Units)
5 = Comp No. 5 (Circuit No. 1 on Scroll Chillers and Condensing Units)
6 = Comp No. 6 (Circuit No. 2 on Scroll Chillers and Condensing Units)
