deTaIled daTa PoInT InformaTIon
www.DaikinApplied.com 71 ED 15062-7 • MICROTECH II CHILLER CONTROLLER
Heat Setpoint
Keypad Menu Path:
Menu
\Set
\Unit SPs (3)
This input network variable provides the heating setpoint when the chiller is operating in the heat
mode. The value is ignored if the controller is in cooling mode. The BACnet property is a commandable
property of a Multi-state Output object. Refer to the appropriate Operation Manual for suitable variable
values. (A50)
Measurement Units Data Type Valid Range Default Value
Temperature
BACnet: °F
LONWORKS: °C
BACnet: Real
LONWORKS: Fixed Point
Scalar signed long
BACnet: 100–150°F
LONWORKS: 37.8–65.6°C
See Below
BACnet
This commandable property sets the temperature of the Leaving Chilled Water when it is in the heating mode.
Variable Details
Object Identier Property Identier
Object Type Type Enumeration Instance Property Name Property Enumeration
Analog Output 0 31 Present Value 85
Object Name
NetworkHeatTempSetpoint
Default Value (Relinquish_Default) 100°F
LONWORKS
This input network variable provides the heating setpoint when the chiller is operating in the heat mode. The value is ignored if the
controller is in cooling mode.
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nviHeatSetpt Chiller temp_p 105 two bytes NA NA
Heat Setpoint
Keypad Menu Path:
No Keypad Equivalent
This conguration network parameter establishes the default Setpoint for the Leaving Water
Temperature when it is in the heating mode, unless the conguration parameter nciDefaults =1 (see
Default Values on page 59). If nciDefaults = 1, the default values are the values specied during
manufacturing. Refer to the appropriate Operating Manual for suitable variable values.
Measurement Units Data Type Valid Range Default Value
Temperature LONWORKS: °C
LONWORKS: Fixed Point
Scalar signed long
LONWORKS: 10–93°C See below
LONWORKS
Default Value 37.8°C
The chiller object uses the conguration value of nciHeatSetpt on power-up or loss of communication unless the conguration
parameter nciDefaults =1 (see Default Values on page 59).
Variable Details
LONWORKS Name Prole SNVT Type SNVT Index SNVT Size SCPT_Reference SCPT Index
nciHeatSetpt Chiller temp_p 105 two bytes SCPT_HeatSetpoint 78
