Daikin MicroTech II Installation And Maintenance Manual

ED 15062-7 • MICROTECH II CHILLER CONTROLLER 22 www.DaikinApplied.com
deTaIled daTa PoInT InformaTIon
Data Point
WSC, WDC,
WPV, HSC, HDC,
TSC, WMC, WCC
AGZ ACZ AGS WGZ, TGZ WGS
Default Values X X X X X X
Design RPM X*****
Device Object X X X X X X
Evaporator Entering Water Temperature X X X X
Evaporator Flow Switch Status X X X X X X
Evaporator Leaving Water Temperature for
Unit
X X X X X
Evaporator Leaving Water Temperature for
Compressor
X X X
Evaporator Pump Run Hours X
Evaporator Refrigerant Pressure X X X X X X
Evaporator Saturated Refrigerant
Temperature
X X X X X X
Evaporator Water Flow Rate X X
Evaporator Water Pump Status X X X X X
Fault Alarms, Analog Input Object X X X X X X
Fault Alarms, Multi-state Input Object X X X X X X
Heat Recovery Entering Water Temperature X
Heat Recovery Leaving Water Temperature X
Heat Setpoint X
Heat Setpoint (LONWORKS Conguration) X
Ice Setpoint X X X X X
IGV Percentage Open X*****
Inverter Temperature X*****
Liquid Line Refrigerant Pressure X****
Liquid Line Refrigerant Temperature X X**** X
Maximum RPM X*****
Maximum Send Time X X X X X X
Minimum RPM X*****
Minimum Send Time X X X X X X
Network Clear Alarm X X X X X
Oil Feed Pressure*** X
Oil Feed Temperature*** X
Oil Sump Pressure*** X
Oil Sump Temperature*** X
Outdoor Air Temperature X X X
Power Factor
Problem Alarms, Analog Input Object X X X X X X
Problem Alarms, Multi-state Input Object X X X X X X
Pump Select X
Receive Heartbeat X X X X X X
Run Enabled X X X X X X
Warning Alarms, Analog Input Object X X X X X X
Warning Alarms, Multi-state Input Object X X X X X X
*Dual Circuit Only
**Optional Solid State Starter Required. Voltage, Power and Current are per compressor
***Not available on the WMC
****AGS A and B vintage only
*****WMC only
