Danfoss iC2 User Manual

Application Guide | iC2-Micro Frequency Converters
Selection number Selection name Selection description
42 Auto Reset Trip An auto reset is performed.
50 Comparator 4 Use result of comparator 4 in logic rule.
51 Comparator 5 Use result of comparator 5 in logic rule.
60 Logic rule 4 Use result of logic rule 4 in logic rule.
61 Logic rule 5 Use result of logic rule 5 in logic rule.
70 SL Time-out 3 Use result of timer 3 in logic rule.
71 SL Time-out 4 Use result of timer 4 in logic rule.
72 SL Time-out 5 Use result of timer 5 in logic rule.
73 SL Time-out 6 Use result of timer 6 in logic rule.
74 SL Time-out 7 Use result of timer 7 in logic rule.
83 Lost Load Lost load is performed.
P 8.4.5.2 Logic Rule Operator 1
Select the 1st logical operator to use on the Boolean inputs from P 8.4.5.1 Logic Rule Boolean 1 and P 8.4.5.3 Logic Rule Boolean 2. This is
an array parameter containing logical operators 0–5.
Default value: 0 Parameter type: Selection
Parameter
number:
1341 Unit: –
Data type: enum Access type: Read/Write
The following are the selections for the parameter.
Selection number Selection name Selection description
0 Disabled Ignores P 8.4.5.3 Logic Rule Boolean 2, P 8.4.5.4 Logic Rule
Operator 2, and P 8.4.5.5 Logic Rule Boolean 3.
1 AND Evaluates expression P 8.4.5.1 Logic Rule Boolean 1 AND P 8.4.5.3
Logic Rule Boolean 2.
2 OR Evaluates expression P 8.4.5.1 Logic Rule Boolean 1 OR P 8.4.5.3
Logic Rule Boolean 2.
3 AND NOT Evaluates expression P 8.4.5.1 Logic Rule Boolean 1 AND NOT P
8.4.5.3 Logic Rule Boolean 2.
4 OR NOT Evaluates expression P 8.4.5.1 Logic Rule Boolean 1 OR NOT P
8.4.5.3 Logic Rule Boolean 2.
5 NOT AND Evaluates expression NOT P 8.4.5.1 Logic Rule Boolean 1 AND P
8.4.5.3 Logic Rule Boolean 2.
6 NOT OR Evaluates expression NOT P 8.4.5.1 Logic Rule Boolean 1 OR P
8.4.5.3 Logic Rule Boolean 2.
Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254 | 209
