Selection number Selection name Selection description
7 NOT AND NOT Evaluates expression NOT P 8.4.5.1 Logic Rule Boolean 1 AND
NOT P 8.4.5.3 Logic Rule Boolean 2.
8 NOT OR NOT Evaluates expression NOT P 8.4.5.1 Logic Rule Boolean 1 OR NOT
P 8.4.5.3 Logic Rule Boolean 2.
P 8.4.5.3 Logic Rule Boolean 2
Select the 2nd boolean (TRUE or FALSE) input for the selected logic rule. This is an array parameter containing logical rules 0–5.
Default value: 0 Parameter type: Selection
Parameter
number:
1342 Unit: –
Data type: enum Access type: Read/Write
Selection number Selection name Selection description
0 FALSE Enters False in logic rule.
1 TRUE Enters True in logic rule.
2 Running See P 9.4.3.1 Function Relay [5] for description.
3 In range See P 9.4.3.1 Function Relay [7] for description.
4 On reference See P 9.4.3.1 Function Relay [8] for description.
7 Out of current range See P 9.4.3.1 Function Relay [12] for description.
8 Below I low See P 9.4.3.1 Function Relay [13] for description.
9 Above I high See P 9.4.3.1 Function Relay [14] for description.
16 Thermal warning See P 9.4.3.1 Function Relay [21] for description.
17 Mains out of range Mains voltage is outside the specified voltage range.
18 Reversing See P 9.4.3.1 Function Relay [25] for description.
19 Warning A warning is active.
20 Alarm (trip) A trip alarm is active.
21 Alarm (trip lock) A trip lock alarm is active.
22 Comparator 0 Use result of comparator 0 in logic rule.
23 Comparator 1 Use result of comparator 1 in logic rule.
24 Comparator 2 Use result of comparator 2 in logic rule.
25 Comparator 3 Use result of comparator 3 in logic rule.
26 Logic rule 0 Use result of logic rule 0 in logic rule.
27 Logic rule 1 Use result of logic rule 1 in logic rule.
28 Logic rule 2 Use result of logic rule 2 in logic rule.
