Application Guide | iC2-Micro Frequency Converters
Selection number Selection name Selection description
29 Logic rule 3 Use result of logic rule 3 in logic rule.
30 SL Time-out 0 Use result of timer 0 in logic rule.
31 SL Time-out 1 Use result of timer 1 in logic rule.
32 SL Time-out 2 Use result of timer 2 in logic rule.
33 Digital input T13 Use value of DI1 in logic rule.
34 Digital input T14 Use value of DI2 in logic rule.
35 Digital input T15 Use value of DIO in logic rule.
36 Digital input T17 Use value of DI3 in logic rule.
39 Start command This event is True, if frequency converter is started by any means
(digital input or other).
40 Drive stopped This event is True, if frequency converter is stopped or coasted by
any means (digital input or other).
42 Auto Reset Trip An auto reset is performed.
50 Comparator 4 Use result of comparator 4 in logic rule.
51 Comparator 5 Use result of comparator 5 in logic rule.
60 Logic rule 4 Use result of logic rule 4 in logic rule.
61 Logic rule 5 Use result of logic rule 5 in logic rule.
70 SL Time-out 3 Use result of timer 3 in logic rule.
71 SL Time-out 4 Use result of timer 4 in logic rule.
72 SL Time-out 5 Use result of timer 5 in logic rule.
73 SL Time-out 6 Use result of timer 6 in logic rule.
74 SL Time-out 7 Use result of timer 7 in logic rule.
83 Lost Load Lost load is performed.
P 8.4.5.4 Logic Rule Operator 2
Select the 2nd logical operator to be used on the Boolean input calculated in P 8.4.5.1 Logic Rule Boolean 1, P 8.4.5.2 Logic Rule Operator
1, and P 8.4.5.3 Logic Rule Boolean 2, and the boolean input coming from P 8.4.5.5 Logic Rule Boolean 3. This is an array parameter
containing logical operators 0–5.
Default value: 0 Parameter type: Selection
Parameter
number:
1343 Unit: –
Data type: enum Access type: Read/Write
The following are the selections for the parameter.
Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254 | 211
