Selection number Selection name Selection description
0 Disabled Ignores P 8.4.5.5 Logic Rule Boolean 3.
1 AND Evaluates expression [P 8.4.5.1 Logic Rule Boolean 1/P 8.4.5.3
Logic Rule Boolean 2] AND P 8.4.5.5 Logic Rule Boolean 3.
2 OR Evaluates expression [P 8.4.5.1 Logic Rule Boolean 1/P 8.4.5.3
Logic Rule Boolean 2] OR P 8.4.5.5 Logic Rule Boolean 3.
3 AND NOT Evaluates expression [P 8.4.5.1 Logic Rule Boolean 1/P 8.4.5.3
Logic Rule Boolean 2] AND NOT P 8.4.5.5 Logic Rule Boolean 3.
4 OR NOT Evaluates expression [P 8.4.5.1 Logic Rule Boolean 1/P 8.4.5.3
Logic Rule Boolean 2] OR NOT P 8.4.5.5 Logic Rule Boolean 3.
5 NOT AND Evaluates expression NOT [P 8.4.5.1 Logic Rule Boolean 1/P
8.4.5.3 Logic Rule Boolean 2] AND P 8.4.5.5 Logic Rule Boolean 3.
6 NOT OR Evaluates expression NOT [P 8.4.5.1 Logic Rule Boolean 1/P
8.4.5.3 Logic Rule Boolean 2] OR P 8.4.5.5 Logic Rule Boolean 3.
7 NOT AND NOT Evaluates expression NOT [P 8.4.5.1 Logic Rule Boolean 1/P
8.4.5.3 Logic Rule Boolean 2] AND NOT P 8.4.5.5 Logic Rule
Boolean 3.
8 NOT OR NOT Evaluates expression NOT [P 8.4.5.1 Logic Rule Boolean 1/P
8.4.5.3 Logic Rule Boolean 2] OR NOT P 8.4.5.5 Logic Rule Boolean
3.
P 8.4.5.5 Logic Rule Boolean 3
Select the 3rd boolean (TRUE or FALSE) input for the selected logic rule. This is an array parameter containing logical rules 0–5.
Default value: 0 Parameter type: Selection
Parameter
number:
1344 Unit: –
Data type: enum Access type: Read/Write
Selection number Selection name Selection description
0 FALSE Enters False in logic rule.
1 TRUE Enters True in logic rule.
2 Running See P 9.4.3.1 Function Relay [5] for description.
3 In range See P 9.4.3.1 Function Relay [7] for description.
4 On reference See P 9.4.3.1 Function Relay [8] for description.
7 Out of current range See P 9.4.3.1 Function Relay [12] for description.
8 Below I low See P 9.4.3.1 Function Relay [13] for description.
9 Above I high See P 9.4.3.1 Function Relay [14] for description.
16 Thermal warning See P 9.4.3.1 Function Relay [21] for description.
212 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
