Application Guide | iC2-Micro Frequency Converters
Selection number Selection name Selection description
17 Mains out of range Mains voltage is outside the specified voltage range.
18 Reversing See P 9.4.3.1 Function Relay [25] for description.
19 Warning A warning is active.
20 Alarm (trip) A trip alarm is active.
21 Alarm (trip lock) A trip lock alarm is active.
22 Comparator 0 Use result of comparator 0 in logic rule.
23 Comparator 1 Use result of comparator 1 in logic rule.
24 Comparator 2 Use result of comparator 2 in logic rule.
25 Comparator 3 Use result of comparator 3 in logic rule.
26 Logic rule 0 Use result of logic rule 0 in logic rule.
27 Logic rule 1 Use result of logic rule 1 in logic rule.
28 Logic rule 2 Use result of logic rule 2 in logic rule.
29 Logic rule 3 Use result of logic rule 3 in logic rule.
30 SL Time-out 0 Use result of timer 0 in logic rule.
31 SL Time-out 1 Use result of timer 1 in logic rule.
32 SL Time-out 2 Use result of timer 2 in logic rule.
33 Digital input T13 Use value of DI1 in logic rule.
34 Digital input T14 Use value of DI2 in logic rule.
35 Digital input T15 Use value of DIO in logic rule.
36 Digital input T17 Use value of DI3 in logic rule.
39 Start command This event is True, if frequency converter is started by any means
(digital input or other).
40 Drive stopped This event is True, if frequency converter is stopped or coasted by
any means (digital input or other).
42 Auto Reset Trip An auto reset is performed.
50 Comparator 4 Use result of comparator 4 in logic rule.
51 Comparator 5 Use result of comparator 5 in logic rule.
60 Logic rule 4 Use result of logic rule 4 in logic rule.
61 Logic rule 5 Use result of logic rule 5 in logic rule.
70 SL Time-out 3 Use result of timer 3 in logic rule.
71 SL Time-out 4 Use result of timer 4 in logic rule.
72 SL Time-out 5 Use result of timer 5 in logic rule.
73 SL Time-out 6 Use result of timer 6 in logic rule.
Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254 | 213
