Danfoss VLT AQUA Drive FC 202

10% duty cycle, horizontal braking, T2
FC 202 Horizontal braking 10% duty cycle
Adjustable frequency drive data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW (hp)]
Danfoss part number Cable
cross-
section
[mm
2
(AWG)]
Thermo
relay
[A]
Line
power
type
P
m
[kW
(hp)]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T2
0.25
(0.34)
380 691.3 630
0.100
(0.134)
175u3002 - - - 1.5 (16) 0.4
T2 0.37 (0.5) 380 466.7 410
0.100
(0.134)
175u3004 - - - 1.5 (16) 0.5
T2
0.55
(0.75)
275 313.7 300
0.100
(0.134)
175u3006 - - - 1.5 (16) 0.6
T2 0.75 (1.0) 188 230.0 200
0.100
(0.134)
175u3011 - - - 1.5 (16) 0.7
T2 1.1 (1.5) 130 152.9 145
0.100
(0.134)
175u3016 - - - 1.5 (16) 0.8
T2 1.5 (2) 81.0 110.5 100
0.100
(0.134)
175u3021 - - - 1.5 (16) 0.9
T2 2.2 (3) 58.5 74.1 70
0.200
(0.268)
175u3026 - - - 1.5 (16) 1.6
T2 3 (4) 45.0 53.7 48
0.200
(0.268)
175u3031 - - - 1.5 (16) 1.9
T2 3.7 (5) 31.5 39.9 35
0.300
(0.402)
175u3325 - - - 1.5 (16) 2.7
T2 5.5 (7.5) 22.5 28.7 27
0.360
(0.483)
175u3326 175u3477 175u3478 - 1.5 (16) 3.5
T2 7.5 (10) 17.7 20.8 18
0.570
(0.764)
175u3327 175u3442 175u3441 - 1.5 (16) 5.3
T2 11 (15) 12.6 14.0 13
0.680
(0.912)
175u3328 175u3059 175u3060 - 1.5 (16) 6.8
T2 15 (20) 8.7 10.2 9.0
1.130
(1.515)
175u3329 175u3068 175u3069 - 2.5 (14) 10.5
T2 25 (18.5) 5.3 8.2 5.7
1.400
(1.877)
175u3330 175u3073 175u3074 - 4 (12) 15
T2 22 (30) 5.1 6.9 5.7
1.700
(2.279)
175u3331 175u3483 175u3484 - 4 (12) 16
T2 30 (40) 3.2 5.0 3.5
2.200
(2.949)
175u3332 175u3080 175u3081 - 6 (10) 24
T2 37 (50) 3.0 4.1 3.5
2.800
(3.753)
175u3333 175u3448 175u3447 - 10 (8) 27
T2 45 (60) 2.4 3.3 2.8
3.200
(4.289)
175u3334 175u3086 175u3087 - 16 (6) 32
Table 6.7 T2, Horizontal Braking 10% Duty Cycle, Recommended Brake Resistors
