Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P1K1 P1K5 P2K2 P3K0 P3K7
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 1.1 1.5 2.2 3.0 3.7
Typical shaft output at 208 V [hp] 1.5 2 3 4 5
Protection rating IP20/Chassis
6)
Protection rating IP21/Type 1
A2 A2 A2 A3 A3
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous (3x200–240 V) [A] 6.6 7.5 10.6 12.5 16.7
Intermittent (3x200–240 V) [A] 9.9 7.3 11.3 8.3 15.9 11.7 18.8 13.8 25 18.4
Continuous kVA at 208 V [kVA] 2.38 2.70 3.82 4.50 6.00
Maximum input current
Continuous (3x200–240 V) [A] 5.9 6.8 9.5 11.3 15.0
Intermittent (3x200–240 V) [A] 8.9 6.5 10.2 7.5 14.3 10.5 17.0 12.4 22.5 16.5
Maximum pre-fuses [A] 20 20 20 32 32
Additional specications
Maximum cable cross-section
2)
for line power, motor,
brake, and load sharing [mm
2
] ([AWG])
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
Maximum cable cross-section
2)
for line power
disconnect
[mm
2
] [(AWG)]
6, 4, 4 (10, 12, 12)
Estimated power loss
3)
at rated maximum load [W]
4)
63 82 116 155 185
Eciency
5)
0.96 0.96 0.96 0.96 0.96
Table 7.3 Line Power Supply 3x200–240 V AC, P1K1–P3K7
Specications
VLT
®
AQUA Drive FC 202
150 Danfoss A/S © 09/2014 All rights reserved. MG20N622
