Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P5K5 P7K5 P11K P15K
High/normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output [kW] 3.7 5.5 5.5 7.5 7.5 11 11 15
Typical shaft output at 208 V [hp] 5.0 7.5 7.5 10 10 15 15 20
IP20/Chassis
7)
B3 B3 B3 B4
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
B1 B1 B1 B2
Output current
Continuous (3x200–240 V) [A] 16.7 24.2 24.2 30.8 30.8 46.2 46.2 59.4
Intermittent (3x200–240 V) [A] 26.7 26.6 38.7 33.9 49.3 50.8 73.9 65.3
Continuous kVA at 208 V [kVA] 6.0 8.7 8.7 11.1 11.1 16.6 16.6 21.4
Maximum input current
Continuous (3x200–240 V) [A] 15.0 22.0 22.0 28.0 28.0 42.0 42.0 54.0
Intermittent (3x200–240 V) [A] 24.0 24.2 35.2 30.8 44.8 46.2 67.2 59.4
Maximum pre-fuses [A] 63 63 63 80
Additional specications
IP20 maximum cable cross-section
2)
for line power,
brake, motor, and load sharing [mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, -, - (2, -, -)
Protection rating IP21 maximum cable cross-section
2)
for line power, brake, and load sharing [mm
2
] ([AWG])
16, 10, 16 (6, 8, 6) 16, 10, 16 (6, 8, 6) 16, 10, 16 (6, 8, 6) 35, -, - (2, -, -)
Protection rating IP21 maximum cable cross-section
2)
for motor
[mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, 25, 25 (2, 4, 4)
Maximum cable cross-section
2)
for line power
disconnect
[mm
2
] ([AWG])
16, 10, 10 (6, 8, 8) 35 (2)
Estimated power loss
3)
at rated maximum load [W]
4)
239 310 239 310 371 514 463 602
Eciency
5)
0.96 0.96 0.96 0.96
Table 7.4 Line Power Supply 3x200–240 V AC, P5K5–P15K
Specications Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 151
7 7
