Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P18K P22K P30K P37K P45K
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 15 18.5 18.5 22 22 30 30 37 37 45
Typical shaft output at 208 V [hp] 20 25 25 30 30 40 40 50 50 60
Protection rating IP20/Chassis
7)
B4 C3 C3 C4 C4
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
C1 C1 C1 C2 C2
Output current
Continuous (3x200–240 V) [A] 59.4 74.8 74.8 88.0 88.0 115 115 143 143 170
Intermittent (3x200–240 V) [A] 89.1 82.3 112 96.8 132 127 173 157 215 187
Continuous kVA at 208 V [kVA] 21.4 26.9 26.9 31.7 31.7 41.4 41.4 51.5 51.5 61.2
Maximum input current
Continuous (3x200–240 V) [A] 54.0 68.0 68.0 80.0 80.0 104 104 130 130 154.0
Intermittent (3x200–240 V) [A] 81.0 74.8 102 88.0 120 114 156 143 195 169.0
Maximum pre-fuses [A] 125 125 160 200 250
Additional specications
Protection rating IP20 maximum cable cross-
section for line power, brake, motor, and
load sharing
[mm
2
] ([AWG])
35 (2) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
Protection ratings IP21, IP55, IP66 maximum
cable cross-section for line power and motor
[mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
Protection ratings IP21, IP55, IP66 maximum
cable cross-section for brake, and load
sharing [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Maximum cable cross-section
2)
for
disconnect [mm
2
] ([AWG])
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
Estimated power loss
3)
at rated maximum
load [W]
4)
624 737 740 845 874 1140 1143 1353 1400 1636
Eciency
5)
0.96 0.97 0.97 0.97 0.97
Table 7.5 Line Power Supply 3x200–240 V AC, P18K–P45K
