Type designation P11K P15K P18K P22K P30K
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output at 550 V [kW] 5.9 7.5 7.5 11 11 15 15 18.5 18.5 22
Typical shaft output at 550 V [hp] 7.5 10 10 15 15 20 20 25 25 30
Typical shaft output at 690 V [kW] 7.5 11 11 15 15 18.5 18.5 22 22 30
Typical shaft output at 690 V [hp] 10 15 15 20 20 25 25 30 30 40
Protection rating IP20/Chassis B4 B4 B4 B4 B4
Protection rating IP21/Type 1
Protection rating IP55/Type 12 B2 B2 B2 B2 B2
Output current
Continuous (3x525–550 V) [A] 11 14 14.0 19.0 19.0 23.0 23.0 28.0 28.0 36.0
Intermittent (60 s overload) (3x525–550 V)
[A]
17.6 15.4 22.4 20.9 30.4 25.3 36.8 30.8 44.8 39.6
Continuous (3x551–690 V) [A] 10 13 13.0 18.0 18.0 22.0 22.0 27.0 27.0 34.0
Intermittent (60 s overload) (3x551–690 V)
[A]
16 14.3 20.8 19.8 28.8 24.2 35.2 29.7 43.2 37.4
Continuous kVA at 550 V [kVA] 10 13.3 13.3 18.1 18.1 21.9 21.9 26.7 26.7 34.3
Continuous kVA at 690 V kVA] 12 15.5 15.5 21.5 21.5 26.3 26.3 32.3 32.3 40.6
Maximum input current
Continuous at 550 V [A] 9.9 15 15.0 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) at 550 V [A] 15.8 16.5 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Continuous (at 690 V) [A] 9 14.5 14.5 19.5 19.5 24.0 24.0 29.0 29.0 36.0
Intermittent (60 s overload) at 690 V [A] 14.4 16 23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Additional specications
Maximum cable cross-section
2
for line
power, motor, brake, and load sharing [mm
2
]
([AWG])
35, 25, 25
(2, 4, 4)
Maximum cable cross-section
2)
for line
power disconnect [mm
2
] ([AWG])
16,10,10
(6, 8, 8)
Estimated power loss
3)
at rated maximum load [W]
4)
150 220 150 220 220 300 300 370 370 440
Eciency
5)
0.98 0.98 0.98 0.98 0.98
Table 7.16 B2/B4 Enclosure, Line Power Supply 3x525–690 V AC IP20/IP21/IP55, Chassis/NEMA 1/NEMA 12, P11K–P22K
Specications Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 163
