Danfoss VLT AQUA Drive FC 202 Design Guide

Type Designation
P37K P45K P55K
P75K/N75K
8)
P90K/N90K
8)
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output at 550 V [kW] 22 30 30 37 37 45 45 55 55 75
Typical shaft output at 550 V [hp] 30 40 40 50 50 60 60 75 75 100
Typical shaft output at 690 V [kW] 30 37 37 45 45 55 55 75 75 90
Typical shaft output at 690 V [hp] 40 50 50 60 60 75 75 100 199 125
Protection rating IP20/Chassis B4 C3 C3 D3h D3h
Protection rating IP21/Type 1
Protection rating IP55/Type 12 C2 C2 C2 C2 C2
Output current
Continuous (3x525–550 V) [A] 36.0 43.0 43.0 54.0 54.0 65.0 65.0 87.0 87.0 105
Intermittent (60 s overload) (3x525–550 V) [A] 54.0 47.3 64.5 59.4 81.0 71.5 97.5 95.7 130.5 115.5
Continuous (3x551–690 V) [A] 34.0 41.0 41.0 52.0 52.0 62.0 62.0 83.0 83.0 100
Intermittent (60 s overload) (3x551–690 V) [A] 51.0 45.1 61.5 57.2 78.0 68.2 93.0 91.3 124.5 110
Continuous kVA at 550 V [kVA] 34.3 41.0 41.0 51.4 51.4 61.9 61.9 82.9 82.9 100
Continuous kVA at 690 V [kVA] 40.6 49.0 49.0 62.1 62.1 74.1 74.1 99.2 99.2 119.5
Maximum input current
Continuous at 550 V [A] 36.0 49.0 49.0 59.0 59.0 71.0 71.0 87.0 87.0 99.0
Intermittent (60 s overload) at 550 V [A] 54.0 53.9 72.0 64.9 87.0 78.1 105.0 95.7 129 108.9
Continuous at 690 V [A] 36.0 48.0 48.0 58.0 58.0 70.0 70.0 86.0 - -
Intermittent (60 s overload) at 690 V [A] 54.0 52.8 72.0 63.8 87.0 77.0 105 94.6 - -
Additional specications
Maximum cable cross-section for line power
and motor [mm
2
] ([AWG])
150 (300 MCM)
Maximum cable cross-section for brake and
load sharing [mm
2
] ([AWG])
95 (3/0)
Maximum cable cross-section
2)
for line power
disconnect [mm
2
] ([AWG])
95 (3/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
-
Estimated power loss
3)
at rated maximum load [W]
4)
600 740 740 900 900 1100 1100 1500 1500 1800
Eciency
5)
0.98 0.98 0.98 0.98 0.98
Table 7.17 B4, C2, C3 Enclosure, Line Power Supply 3x525–690 V AC IP20/IP21/IP55, Chassis/NEMA1/NEMA 12, P30K–P75K
For fuse ratings, see chapter 7.7 Fuses and Circuit Breakers.
1) High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2) The three values for the maximum cable cross-section are for single core,
exible wire and exible wire with sleeve, respectively.
3) Applies for dimensioning of adjustable frequency drive cooling. If the switching frequency is higher than the default setting, the power losses
may increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
www.danfoss.com/vltenergyeciency.
4) Eciency measured at nominal current. For energy eciency class, see chapter 7.4 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyeciency.
5) Measured using 5 m (10 ft) shielded motor cables at rated load and rated frequency.
6) Enclosure sizes A2+A3 can be converted to IP21 using a conversion kit. See also chapter 3.6 Mechanical Planning.
7) Enclosure sizes B3+B4 and C3+C4 can be converted to IP21 using a conversion kit. See also chapter 3.6 Mechanical Planning.
8) Enclosure sizes for N75K, N90K are D3h for IP20/Chassis, and D5h for IP54/Type 12.
9) 2 wires are required.
10) Variant not available in IP21.
Specications
VLT
®
AQUA Drive FC 202
164 Danfoss A/S © 09/2014 All rights reserved. MG20N622
