Danfoss VLT AQUA Drive FC 202 Design Guide

3x380–480 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power
[kW (hp)]
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
- KTS-R-6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1.1–2.2
(1.5–3)
KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3 (4) KTS-R-15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4 (5) KTS-R-20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 (7.5) KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 (10) KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11 (15) KTS-R-40 JKS-40 JJS-40 - - -
15 (20) KTS-R-50 JKS-50 JJS-50 - - -
22 (30) KTS-R-60 JKS-60 JJS-60 - - -
30 (40) KTS-R-80 JKS-80 JJS-80 - - -
37 (50) KTS-R-100 JKS-100 JJS-100 - - -
45 (60) KTS-R-125 JKS-125 JJS-125 - - -
55 (75) KTS-R-150 JKS-150 JJS-150 - - -
75 (100) KTS-R-200 JKS-200 JJS-200 - - -
90 (125) KTS-R-250 JKS-250 JJS-250 - - -
Table 7.27 3x380–480 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power
[kW (hp)]
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
Bussmann
JFHR2
Ferraz-
Shawmut
J
Ferraz-
Shawmut
JFHR2
1)
Littelfuse
JFHR2
- 5017906-006 KLS-R-6 ATM-R-6 A6K-6-R FWH-6 HSJ-6 - -
1.1–2.2
(1.5–3)
5017906-010 KLS-R-10 ATM-R-10 A6K-10-R FWH-10 HSJ-10 - -
3 (4) 5017906-016 KLS-R-15 ATM-R-15 A6K-15-R FWH-15 HSJ-15 - -
4 (5) 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R FWH-20 HSJ-20 - -
5.5 (7.5) 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R FWH-25 HSJ-25 - -
7.5 (10) 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R FWH-30 HSJ-30 - -
11 (15) 5014006-040 KLS-R-40 - A6K-40-R FWH-40 HSJ-40 - -
15 (20) 5014006-050 KLS-R-50 - A6K-50-R FWH-50 HSJ-50 - -
22 (30) 5014006-063 KLS-R-60 - A6K-60-R FWH-60 HSJ-60 - -
30 (40) 2028220-100 KLS-R-80 - A6K-80-R FWH-80 HSJ-80 - -
37 (50) 2028220-125 KLS-R-100 - A6K-100-R FWH-100 HSJ-100 - -
45 (60) 2028220-125 KLS-R-125 - A6K-125-R FWH-125 HSJ-125 - -
55 (75) 2028220-160 KLS-R-150 - A6K-150-R FWH-150 HSJ-150 - -
75 (100) 2028220-200 KLS-R-200 - A6K-200-R FWH-200 HSJ-200 A50-P-225 L50-S-225
90 (125) 2028220-250 KLS-R-250 - A6K-250-R FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 7.28 3x380–480 V, Enclosure Sizes A, B, and C
1) Ferraz-Shawmut A50QS fuses may substitute A50P fuses.
