A6KR fuses from Ferraz-Shawmut may substitute A2KR for 240 V adjustable frequency drives.
3x200–240 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power [kW
(hp)]
Bussmann
Type RK1
1)
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann Bussmann
Type CC
0.25–0.37
(0.34–0.5)
KTN-R-05 JKS-05 JJN-05 FNQ-R-5 KTK-R-5 LP-CC-5
0.55–1.1
(0.75–1.5)
KTN-R-10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1.5 (2) KTN-R-15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2.2 (3) KTN-R-20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3.0 (4) KTN-R-25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3.7 (5) KTN-R-30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5.5–7.5 (7.5–
10)
KTN-R-50 JKS-50 JJN-50 - - -
11 (15) KTN-R-60 JKS-60 JJN-60 - - -
15 (20) KTN-R-80 JKS-80 JJN-80 - - -
18.5–22 KTN-R-125 JKS-125 JJN-125 - - -
30 (40) KTN-R-150 JKS-150 JJN-150 - - -
37 (50) KTN-R-200 JKS-200 JJN-200 - - -
45 (60) KTN-R-250 JKS-250 JJN-250 - - -
Table 7.25 3x200–240 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power [kW
(hp)]
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
2)
Bussmann
Type JFHR2
3)
Littelfuse
JFHR2
Ferraz-
Shawmut
JFHR2
4)
Ferraz-
Shawmut
J
0.25–0.37
(0.34–0.5)
5017906-005 KLN-R-05 ATM-R-05 A2K-05-R FWX-5 - - HSJ-6
0.55–1.1
(0.75–1.5)
5017906-010 KLN-R-10 ATM-R-10 A2K-10-R FWX-10 - - HSJ-10
1.5 (2) 5017906-016 KLN-R-15 ATM-R-15 A2K-15-R FWX-15 - - HSJ-15
2.2 (3) 5017906-020 KLN-R-20 ATM-R-20 A2K-20-R FWX-20 - - HSJ-20
3.0 (4) 5017906-025 KLN-R-25 ATM-R-25 A2K-25-R FWX-25 - - HSJ-25
3.7 (5) 5012406-032 KLN-R-30 ATM-R-30 A2K-30-R FWX-30 - - HSJ-30
5.5–7.5
(7.5–10)
5014006-050 KLN-R-50 - A2K-50-R FWX-50 - - HSJ-50
11 (15) 5014006-063 KLN-R-60 - A2K-60-R FWX-60 - - HSJ-60
15 (20) 5014006-080 KLN-R-80 - A2K-80-R FWX-80 - - HSJ-80
18.5–22
(25–30)
2028220-125 KLN-R-125 - A2K-125-R FWX-125 - - HSJ-125
30 (40) 2028220-150 KLN-R-150 - A2K-150-R FWX-150 L25S-150 A25X-150 HSJ-150
37 (50) 2028220-200 KLN-R-200 - A2K-200-R FWX-200 L25S-200 A25X-200 HSJ-200
45 (60) 2028220-250 KLN-R-250 - A2K-250-R FWX-250 L25S-250 A25X-250 HSJ-250
Table 7.26 3x200–240 V, Enclosure Sizes A, B, and C
1) KTS fuses from Bussmann may substitute KTN for 240 V adjustable frequency drives.
2) A6KR fuses from Ferraz-Shawmut may substitute A2KR for 240 V adjustable frequency drives.
3) FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives.
4) A50X fuses from Ferraz-Shawmut may substitute A25X for 240 V adjustable frequency drives.
