Danfoss VLT AQUA Drive FC 202 Design Guide

Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 240 0.244 0.608 1.993
136 240 0.560 0.580 0.832
150 240 0.720 0.574 0.661
Table 7.37 Adjustable Frequency Drive, P22K, T2
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
15 240 0.194 0.626 2.581
50 240 0.252 0.574 1.929
150 240 0.444 0.538 0.977
Table 7.38 Adjustable Frequency Drive, P30K, T2
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
30 240 0.300 0.598 1.593
100 240 0.536 0.566 0.843
150 240 0.776 0.546 0.559
Table 7.39 Adjustable Frequency Drive, P37K, T2
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
30 240 0.300 0.598 1.593
100 240 0.536 0.566 0.843
150 240 0.776 0.546 0.559
Table 7.40 Adjustable Frequency Drive, P45K, T2
380–480 V (T4)
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 400 0.640 0.690 0.862
50 400 0.470 0.985 0.985
150 400 0.760 1.045 0.947
Table 7.41 Adjustable Frequency Drive, P1K5, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 400 0.172 0.890 4.156
50 400 0.310 2.564
150 400 0.370 1.190 1.770
Table 7.42 Adjustable Frequency Drive, P4K0, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 400 0.04755 0.739 8.035
50 400 0.207 1.040 4.548
150 400 0.6742 1.030 2.828
Table 7.43 Adjustable Frequency Drive, P7K5, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
15 400 0.408 0.718 1.402
100 400 0.364 1.050 2.376
150 400 0.400 0.980 2.000
Table 7.44 Adjustable Frequency Drive, P11K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 400 0.422 1.060 2.014
100 400 0.464 0.900 1.616
150 400 0.896 1.000 0.915
Table 7.45 Adjustable Frequency Drive, P15K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 400 0.344 1.040 2.442
100 400 1.000 1.190 0.950
150 400 1.400 1.040 0.596
Table 7.46 Adjustable Frequency Drive, P18K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 400 0.232 0.950 3.534
100 400 0.410 0.980 1.927
150 400 0.430 0.970 1.860
Table 7.47 Adjustable Frequency Drive, P22K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
15 400 0.271 1.000 3.100
100 400 0.440 1.000 1.818
150 400 0.520 0.990 1.510
Table 7.48 Adjustable Frequency Drive, P30K, T4
Specications
Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 183
7 7
