Danfoss VLT AQUA Drive FC 202 Design Guide

Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 480 0.270 1.276 3.781
50 480 0.435 1.184 2.177
100 480 0.840 1.188 1.131
150 480 0.940 1.212 1.031
Table 7.49 Adjustable Frequency Drive, P37K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 400 0.254 1.056 3.326
50 400 0.465 1.048 1.803
100 400 0.815 1.032 1.013
150 400 0.890 1.016 0.913
Table 7.50 Adjustable Frequency Drive, P45K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
10 400 0.350 0.932 2.130
Table 7.51 Adjustable Frequency Drive, P55K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 480 0.371 1.170 2.466
Table 7.52 Adjustable Frequency Drive, P75K, T4
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 400 0.364 1.030 2.264
Table 7.53 Adjustable Frequency Drive, P90K, T4
525–600 V (T6)
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 600 0.304 1.560 4.105
50 600 0.300 1.550 4.133
100 600 0.536 1.640 2.448
150 600 0.576 1.640 2.278
Table 7.54 Adjustable frequency drive, P11K, T6
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
36 600 0.084 1.560 7.962
50 600 0.120 1.540 5.467
100 600 0.165 1.472 3.976
150 600 0.190 1.530 3.432
Table 7.55 Adjustable frequency drive, P22K, T6
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
15 600 0.276 1.184 4.290
Table 7.56 Adjustable frequency drive, P55K, T6
525–690 V (T7)
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
80 690 0.580 1.728 2.369
130 690 0.930 1.824 1.569
180 690 0.925 1.818 1.570
Table 7.57 Adjustable frequency drive, P7K5, 76
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
5 690 0.250 1.440 4.608
105 690 0.570 1.800 2.526
180 690 0.982 1.840 1.499
Table 7.58 Adjustable frequency drive, P45K, T7
Cable
length [m]
AC line
voltage
[V]
Rise time
[μsec]
U
PEAK
[kV]
dU/dt
[kV/μsec]
6 690 0.238 1.416 4.739
50 690 0.358 1.764 3.922
150 690 0.465 1.872 3.252
Table 7.59 Adjustable frequency drive, P55K, T7
