7.9 dU/dt Testing
182
7.10 Acoustic Noise Ratings
185
7.11 Selected Options
185
7.11.1 VLT
®
General Purpose I/O Module MCB 101 185
7.11.2 VLT
®
Relay Card MCB 105 185
7.11.3 VLT
®
PTC Thermistor Card MCB 112 187
7.11.4 VLT
®
Extended Relay Card MCB 113 189
7.11.5 VLT
®
Sensor Input Option MCB 114 190
7.11.6 VLT
®
Extended Cascade Controller MCO 101 191
7.11.7 VLT
®
Advanced Cascade Controller MCO 102 192
8 Appendix - Selected Drawings
195
8.1 AC Line Input Connection Drawings (3-phases)
195
8.2 Motor Connection Drawings
198
8.3 Relay Terminal Drawings
200
8.4 Cable Entry Holes
201
Index
205
