Trip
A state entered in fault situations, e.g. if the frequency converter is subject to an over-temperature or when the frequency converter is protecting the
motor, process or mechanism. Restart is prevented until the cause of the fault has disappeared and the trip state is cancelled by activating reset or, in
some cases, by being programmed to reset automatically. Trip may not be used for personal safety.
Trip Locked
A state entered in fault situations when the frequency converter is protecting itself and requiring physical intervention, e.g. if the frequency converter is
subject to a short circuit on the output. A locked trip can only be cancelled by cutting off mains, removing the cause of the fault, and reconnecting the
frequency converter. Restart is prevented until the trip state is cancelled by activating reset or, in some cases, by being programmed to reset automatically.
Trip may not be used for personal safety.
VT Characteristics
Variable torque characteristics used for pumps and fans.
VVC
plus
If compared with standard voltage/frequency ratio control, Voltage Vector Control (VVC
plus
) improves the dynamics and the stability, both when the speed
reference is changed and in relation to the load torque.
60° AVM
Switching pattern called 60°
Asynchronous Vector Modulation (par. 14-00
Switching Pattern
).
Power Factor
The power factor is the relation between I
1
and I
RMS
.
Power
factor
=
3
x
U
x
I
1
cos
Ï•
3
x
U
x
I
RMS
The power factor for 3-phase control:
=
I
1
x
cos
Ï•1
I
RMS
=
I
1
I
RMS
since
cos
Ï•1 = 1
The power factor indicates to which extent the frequency converter im-
poses a load on the mains supply.
The lower the power factor, the higher the I
RMS
for the same kW per-
formance.
I
RMS
=
I
1
2
+
I
5
2
+
I
7
2
+ .. +
I
n
2
In addition, a high power factor indicates that the different harmonic currents are low.
The frequency converters' built-in DC coils produce a high power factor, which minimizes the imposed load on the mains supply.
1 Introduction VLT
®
HVAC Drive Programming Guide
10
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
1
