16-09 Custom Readout
Range: Function:
0.00 Cus-
tomReadou-
tUnit*
[-999999.99 - 999999.99 Custom-
ReadoutUnit]
View the user-defined readouts as defined in par. 0-30
Custom Readout Unit
, par. 0-31
Custom
Readout Min Value
and par. 0-32
Custom Readout Max Value
.
3.16.3 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range: Function:
0.00 kW* [0.00 - 10000.00 kW] Displays motor power in kW. The value shown is calculated on the basis of the actual motor voltage
and motor current. The value is filtered, and therefore approx. 30 ms may pass from when an input
value changes to when the data read-out values change. The resolution of read-out value on fieldbus
is in 10 W steps.
16-11 Power [hp]
Range: Function:
0.00 hp* [0.00 - 10000.00 hp] View the motor power in HP. The value shown is calculated on the basis of the actual motor voltage
and motor current. The value is filtered, and therefore approximately 30 ms may pass from when
an input value changes to when the data read-out values change.
16-12 Motor Voltage
Range: Function:
0.0 V* [0.0 - 6000.0 V] View the motor voltage, a calculated value used for controlling the motor.
16-13 Frequency
Range: Function:
0.0 Hz* [0.0 - 6500.0 Hz] View the motor frequency, without resonance dampening.
16-14 Motor Current
Range: Function:
0.00 A* [0.00 - 10000.00 A] View the motor current measured as a mean value, IRMS. The value is filtered, and thus approxi-
mately 30 ms may pas s from when an i nput value ch a nges to when th e data read-ou t values cha nge.
16-15 Frequency [%]
Range: Function:
0.00 %* [-100.00 - 100.00 %] View a two-byte word reporting the actual motor frequency (without resonance dampening) as a
percentage (scale 0000-4000 Hex) of par. 4-19
Max Output Frequency
. Set par. 9-16
PCD Read
Configuration
index 1 to send it with the Status Word instead of the MAV.
16-16 Torque [Nm]
Range: Function:
0.0 Nm* [-30000.0 - 30000.0 Nm] View the torque value with sign, applied to the motor shaft. Linearity is not exact between 110%
motor current and torque in relation to the rated torque. Some motors supply more than 160%
torque. Consequently, the min. value and the max. value will depend on the max. motor current as
well as the motor used. The value is filtered, and thus approx. 1.3 seconds may pass from when an
input changes value to when the data read-out values change.
16-17 Speed [RPM]
Range: Function:
0 RPM* [-30000 - 30000 RPM] View the actual motor RPM.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
164
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
