3.11.3 10-1* DeviceNet
Parameters specific to the DeviceNet fieldbus.
10-10 Process Data Type Selection
Option: Function:
Select the Instance (telegram) for data transmission. The Instances available are dependent upon
the setting of par. 8-10
Control Profile
.
When par. 8-10
Control Profile
is set to [0]
FC profile
, par. 10-10
Process Data Type Selection
options
[0] and [1] are available.
When par. 8-10
Control Profile
is set to [5]
ODVA
, par. 10-10
Process Data Type Selection
options
[2] and [3] are available.
Instances 100/150 and 101/151 are Danfoss-specific. Instances 20/70 and 21/71 are ODVA-specific
AC Drive profiles.
For guidelines in telegram selection, please refer to the DeviceNet Operating Instructions.
Note that a change to this parameter will be executed immediately.
[0] * INSTANCE 100/150
[1] INSTANCE 101/151
[2] INSTANCE 20/70
[3] INSTANCE 21/71
10-11 Process Data Config Write
Option: Function:
Select the process write data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array
can be selected. Elements [0] and [1] of the array are fixed.
[0] * None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit [RPM]
[413] Motor Speed High Limit [RPM]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Output Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1680] Fieldbus CTW 1
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
