[0] * Not linked
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 N/A* [0 - 255 N/A] View a list of all the set-ups linked by means of par. 0-12
This Set-up Linked to
. The parameter has
one index for each parameter set-up. The parameter value displayed for each index represents
which setups are linked to that parameter setup.
Index
LCP value
0 {0}
1 {1,2}
2 {1,2}
3{3}
4 {4}
Table 3.2: Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Prog. Set-ups / Channel
Range: Function:
0 N/A* [-2147483648 - 2147483647 N/A] View the setting of par. 0-11
Programming Set-up
for each of the four different communication
channels. When the number is displayed in hex, as it is in the LCP, each number represents one
channel.
Numbers 1-4 represent a set-up number; ‘F’ means factory setting; and ‘A’ means active set-up.
The channels are, from right to left: LCP, FC bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that the FC bus selected Set-up 2 in par. 0-11
Program-
ming Set-up
, the LCP selected Set-up 1 and all others used the active set-up.
3.2.4 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
NB!
Please refer to par. 0-37
Display Text 1
, par. 0-38
Display Text 2
and par. 0-39
Display Text 3
for information on how to write display
texts.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, left position.
[0] * None No display value selected
[37] Display Text 1 Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
[38] Display Text 2 Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
36
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
