Danfoss VLT - Analog out X42;9; Terminal X42;7 Timeout Preset; Terminal X42;9 Output; Terminal X42;9 Min. Scale

26-44 Terminal X42/7 Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %] Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout function is selected in par. 26-50
Terminal X42/9 Output the
output will preset to this level.
3.24.7 26-5* Analog Out X42/9
Parameters for configuring the scaling and output function for analog output, terminal X42/9.
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0] * No operation
[100] Output freq. 0-100 : 0 - 100 Hz, (0-20 mA)
[101] Reference Min-Max : Minimum reference - Maximum reference, (0-20 mA)
[102] Feedback +-200% : -200% to +200% of par. 20-14
Maximum Reference/Feedb. , (0-20 mA)
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current ), (0-20 mA)
[104] Torque 0-Tlim : 0 - Torque limit (par. 4-16
Torque Limit Motor Mode ), (0-20 mA)
[105] Torque 0-Tnom : 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom : 0 - Motor rated power, (0-20 mA)
[107] Speed 0-HighLim : 0 - Speed High Limit (par. 4-13
Motor Speed High Limit [RPM] and par. 4-14 Motor Speed High
Limit [Hz]
), (0-20 mA)
[113] Ext. Closed Loop 1 : 0 - 100%, (0-20 mA)
[114] Ext. Closed Loop 2 : 0 - 100%, (0-20 mA)
[115] Ext. Closed Loop 3 : 0 - 100%, (0-20 mA)
[139] Bus ctrl. : 0 - 100%, (0-20 mA)
[141] Bus ctrl t.o. : 0 - 100%, (0-20 mA)
26-51 Terminal X42/9 Min. Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scale the minimum output of the selected analog signal at terminal X42/9, as a percentage of the
maximum signal level. E.g. if a 0 V is desired at 25% of the maximum output value. Then programme
25%. Scaling values up to 100% can never be higher than the corresponding setting in
par. 26-52
Terminal X42/9 Max. Scale .
See principle graph for par. 6-51
Terminal 42 Output Min Scale .
