Page #236 background imageLoading...
Page #236 background image
24-07 Fire Mode Feedback Source
Option: Function:
Select the feed back input to be used for the Fire Mode feed back signal when Fire Mode is active.
If the motor also is controlled by the built in PID controller when in normal operation, the same
transmitter can be used for both cases by selecting the same source.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
24-09 Fire Mode Alarm Handling
Option: Function:
[0] Trip+Reset, Critical Alarms If this mode is selected, the frequency converter will continue to run, ignoring most alarms, EVEN
IF DOING SO MAY RESULT IN DAMAGE OF THE FREQUENCY CONVERTER. Critical alarms are
alarms, which cannot be suppressed but a restart attempt is possible (Infinity Automatic Reset).
[1] * Trip, Critical Alarms In case of a critical alarm, the frequency converter will trip and not auto-restart (Manual Reset).
[2] Trip, All Alarms/Test It is possible to test the operation of Fire Mode, but all alarm states are activated normally (Manual
Reset).
NB!
Warranty-affecting alarms. Certain alarms can affect
the lifetime of the frequency converter. Should one of
these ignored alarms occur whilst in Fire Mode, a log
of the event is stored in the Fire Mode Log.
Here the 10 latest events of warranty-affecting alarms,
fire mode activation and fire mode deactivation are
stored.
NB!
The setting in par. 14-20
Reset Mode
is disregarded in
case of Fire Mode being active (see par. 24-0*, Fire
Mode).
No: Description
Critical
Alarms
Warranty
Affecting
Alarms
4 Mains ph. Loss x
7DC over volt x
8 DC under volt x
9 Inverter overloaded x
13 Over current x
14 Earth fault x
16 Short circuit x
29 Power card temp x
33 Inrush fault x
38 Internal fault x
65 Ctrl. card temp x
68 SafeStop x
3.22.2 24-1* Drive Bypass
The frequency converter includes a feature, which can be used to automatically activate an external electro-mechanical bypass in case of a trip/trip lock
of the frequency converter or the event of a Fire Mode Coast (see par. 24-00
Fire Mode Function
).
3 Parameter Description VLT
®
HVAC Drive Programming Guide
236
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
