Danfoss VLT Programming Guide

5.1.11 10-** CAN Fieldbus
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
10-0* Common Settings
10-00 CAN Protocol null 2 set-ups FALSE - Uint8
10-01 Baud Rate Select null 2 set-ups TRUE - Uint8
10-02 MAC ID SR 2 set-ups TRUE 0 Uint8
10-05 Readout Transmit Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-06 Readout Receive Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-07 Readout Bus Off Counter 0 N/A All set-ups TRUE 0 Uint8
10-1* DeviceNet
10-10 Process Data Type Selection null All set-ups TRUE - Uint8
10-11 Process Data Config Write SR 2 set-ups TRUE - Uint16
10-12 Process Data Config Read SR 2 set-ups TRUE - Uint16
10-13 Warning Parameter 0 N/A All set-ups TRUE 0 Uint16
10-14 Net Reference [0] Off 2 set-ups TRUE - Uint8
10-15
Net Control [0] Off 2 set-ups TRUE - Uint8
10-2* COS Filters
10-20 COS Filter 1 0 N/A All set-ups FALSE 0 Uint16
10-21 COS Filter 2 0 N/A All set-ups FALSE 0 Uint16
10-22 COS Filter 3 0 N/A All set-ups FALSE 0 Uint16
10-23 COS Filter 4 0 N/A All set-ups FALSE 0 Uint16
10-3* Parameter Access
10-30 Array Index 0 N/A 2 set-ups TRUE 0 Uint8
10-31 Store Data Values [0] Off All set-ups TRUE - Uint8
10-32 Devicenet Revision 0 N/A All set-ups TRUE 0 Uint16
10-33 Store Always [0] Off 1 set-up TRUE - Uint8
10-34 DeviceNet Product Code 120 N/A 1 set-up TRUE 0 Uint16
10-39 Devicenet F Parameters 0 N/A All set-ups TRUE 0 Uint32
5.1.12 11-** LonWorks
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
11-0* LonWorks ID
11-00 Neuron ID 0 N/A All set-ups TRUE 0
OctStr[6
]
11-1* LON Functions
11-10 Drive Profile [0] VSD profile All set-ups TRUE - Uint8
11-15 LON Warning Word 0 N/A All set-ups TRUE 0 Uint16
11-17 XIF Revision 0 N/A All set-ups TRUE 0
VisStr[5
]
11-18 LonWorks Revision 0 N/A All set-ups TRUE 0
VisStr[5
]
11-2* LON Param. Access
11-21 Store Data Values [0] Off All set-ups TRUE - Uint8
5 Parameter Lists VLT
®
HVAC Drive Programming Guide
286 MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
5
