NB!
The counters starts counting whenever the frequency converter is powered-up. Power cycle shortly after a reset will zero the counters.
EEProm data are updated once per hour.
23-60 Trend Variable
Option: Function:
Select the desired operating variable to be monitored for Trending.
[0] * Power [kW] Power yielded to the motor. Reference for the relative value is the rated motor power programmed
in par. 1-20
Motor Power [kW]
or par. 1-21
Motor Power [HP]
. Actual value can be read in
par. 16-10
Power [kW]
or par. 16-11
Power [hp]
.
[1] Current [A] Output current to the motor. Reference for the relative value is the rated motor current programmed
in par. 1-24
Motor Current
. Actual value can be read in par. 16-14
Motor Current
.
[2] Frequency [Hz] Output frequency to the motor. Reference for the relative value is the maximum output frequency
programmed in par. 4-14
Motor Speed High Limit [Hz]
. Actual value can be read in
par. 16-13
Frequency
.
[3] Motor Speed [RPM] Speed of the motor. Reference for relative value is the maximum motor speed programmed in
par. 4-13
Motor Speed High Limit [RPM]
.
23-61 Continuous Bin Data
Range: Function:
0 N/A* [0 - 4294967295 N/A] Array with 10 elements ([0]-[9] below parameter number in display). Press OK and step between
elements by means of
and
buttons on the LCP.
10 counters with the frequency of occurrence for the operating variable monitored, sorted according
to the following intervals:
Counter [0]: 0% - <10%
Counter [1]: 10% - <20%
Counter [2]. 20% - <30%
Counter [3]: 30% - <40%
Counter [4]: 40% - <50%
Counter [5]: 50% - <60%
Counter [6]. 60% - <70%
Counter [7]: 70% - <80%
Counter [8]. 80% - <90%
Counter [9]: 90% - <100% or Max
The above minimum limits for the intervals are the default limits. These can be changed in
par. 23-65
Minimum Bin Value
.
Starts to count when the frequency converter is powered up for the first time. All counters can be
reset to 0 in par. 23-66
Reset Continuous Bin Data
.
23-62 Timed Bin Data
Range: Function:
0 N/A* [0 - 4294967295 N/A] Array with 10 elements ([0]-[9] below parameter number in display). Press OK and step between
elements by means of
and
buttons on the LCP.
10 counters with the frequency of occurrence for the operating data monitored sorted according to
the intervals as for par. 23-61
Continuous Bin Data
.
Starts to count at the date/time programmed in par. 23-63
Timed Period Start
, and stops at the
time/date programmed in par. 23-64
Timed Period Stop
. All counters can be reset to 0 in
par. 23-67
Reset Timed Bin Data
.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
228
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
