Danfoss VLT Programming Guide

[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option: Function:
[0] * Log always Select Log always [0] for continuous logging.
[1] Log once on trigger Select
Log once on trigger [1] to conditionally start and stop logging using par. 15-12 Trigger
Event
and par. 15-14 Samples Before Trigger .
15-14 Samples Before Trigger
Range: Function:
50 N/A* [0 - 100 N/A] Enter the percentage of all samples prior to a trigger event which are to be retained in the log. See
also par. 15-12
Trigger Event and par. 15-13 Logging Mode .
3 Parameter Description VLT
®
HVAC Drive Programming Guide
158 MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
