[74] Logic Rule 4 If Logic Rule 4 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[75] Logic Rule 5 If Logic Rule 5 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[80] SL Digital Output A SL Controller Action. The input will go high whenever the Smart Logic Action [38] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [32] Set dig. out. A low is
executed.
[81] SL Digital Output B SL Controller Action. The input will go high whenever the Smart Logic Action [39] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [33] Set dig. out. A low is
executed.
[82] SL Digital Output C SL Controller Action. The input will go high whenever the Smart Logic Action [40] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [34] Set dig. out. A low is
executed.
[83] SL Digital Output D SL Controller Action. The input will go high whenever the Smart Logic Action [41] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [35] Set dig. out. A low is
executed.
[84] SL Digital Output E SL Controller Action. The input will go high whenever the Smart Logic Action [42] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [36] Set dig. out. A low is
executed.
[85] SL Digital Output F SL Controller Action. The input will go high whenever the Smart Logic Action [43] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [37] Set dig. out. A low is
executed
3.9.4 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option: Function:
Protocol selection for the integrated FC (standard) Port (RS485) on the control card.
Parameter group 8-7* is only visible when FC Option [9] is chosen.
[0] * FC Communication according to the FC Protocol as described in the
VLT HVAC Drive Design Guide,
RS485 Installation and Set-up
.
[1] FC MC Same as
FC [0] but to be used when downloading SW to the frequency converter or uploading dll
file (covering information regarding parameters available in the frequency converter and their inter-
dependencies) to Motion Control Tool MCT10.
[2] Modbus RTU Communication according to the Modbus RTU protocol as described in the
VLT HVAC Drive Design
Guide, RS485 Installation and Set-up
.
[3] Metasys N2 Communication protocol. The N2 software protocol is designed to be general in nature in order to
accommodate the unique properties each device may have. Please see separate manual
VLT HVAC
Drive Metasys MG.11.Gx.yy
.
[4] FLN
[9] FC Option To be used when a gateway is connected to the integrated RS485 port, e.g. the BACnet gateway.
Following changes will take place:
-Address for the FC port will be set to 1 and par. 8-31
Address , is now used to set the address for
the gateway on the network, e.g. BACnet.
Please see separate manual
VLT HVAC Drive BACnet, MG.11.Dx.yy .
-Baud rate for the FC port will be set to a fixed value (115.200 Baud) and par. 8-32
Baud Rate , is
now used to set the baud rate for the network port (e.g. BACnet) on the gateway.
[20] LEN
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark 105
