[9927] HS Temp. (PC8)
NB!
Please consult the
VLT HVAC Drive Programming Guide, MG.11.CX.YY
for detailed information.
0-21 Display Line 1.2 Small
Select a variable for display in line 1, middle position.
Option: Function:
[1614] * Motor Current The options are the same as those listed in par. 0-20
Display Line 1.1 Small
.
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position.
Option: Function:
[1610] * Power [kW] The options are the same as those listed in par. 0-20
Display Line 1.1 Small
.
0-23 Display Line 2 Large
Select a variable for display in line 2.
Option: Function:
[1613] * Frequency The options are the same as those listed in par. 0-20
Display Line 1.1 Small
.
0-24 Display Line 3 Large
Select a variable for display in line 3.
Option: Function:
[1502] * kWh Counter The options are the same as those listed in par. 0-20
Display Line 1.1 Small
.
0-25 My Personal Menu
Array [20]
Range: Function:
Application
dependent*
[0 - 9999 N/A] Define up to 20 parameters to appear in the Q1 Personal Menu, accessible via the [Quick Menu]
key on the LCP. The parameters will be displayed in the Q1 Personal Menu in the order they are
programmed into this array parameter. Delete parameters by setting the value to ‘0000’.
For example, this can be used to provide quick, simple access to just one or up to 20 parameters
which require changing on a regular basis (e.g. for plant maintenance reasons) or by an OEM to
enable simple commissioning of their equipment.
3.2.5 0-3*LCP Custom Readout
It is possible to customize the display elements for various purposes: *Custom Readout. Value proportional to speed (Linear, squared or cubed depending
on unit selected in par. 0-30
Custom Readout Unit
) *Display Text. Text string stored in a parameter.
Custom Readout
The calculated value to be displayed is based on settings in par. 0-30
Custom Readout Unit
, par. 0-31
Custom Readout Min Value
(linear only),
par. 0-32
Custom Readout Max Value
, par. 4-13
Motor Speed High Limit [RPM]
, par. 4-14
Motor Speed High Limit [Hz]
and actual speed.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
40
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
