8-07 Diagnosis Trigger
Option: Function:
This parameter has no function for BACnet.
[0] * Disable
[1] Trigger on alarms
[2] Trigger alarm/warn.
3.9.3 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Profile
Option: Function:
Select the interpretation of the control and status words corresponding to the installed fieldbus.
Only the selections valid for the fieldbus installed in slot A will be visible in the LCP display.
[0] * FC profile
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of bits 12 – 15 in the status word.
[0] No function The input is always low.
[1] * Profile Default Depended on the profile set in Parameter 8-10.
[2] Alarm 68 Only The input will go high whenever Alarm 68 is active and will go low whenever no alarm 68 is active
[3] Trip excl Alarm 68 The input will go high whenever Trip on other Alarms then Alarm 68 is active.
[10] T18 DI status. The input will go high whenever T18 has 24V and will go low whenever T18 has 0V
[11] T19 DI status. The input will go high whenever T19 has 24V and will go low whenever T19 has 0V
[12] T27 DI status. The input will go high whenever T27 has 24V and will go low whenever T27 has 0V
[13] T29 DI status. The input will go high whenever T29 has 24V and will go low whenever T29 has 0V
[14] T32 DI status. The input will go high whenever T32 has 24V and will go low whenever T32 has 0V
[15] T33 DI status. The input will go high whenever T33 has 24V and will go low whenever T33 has 0V
[16] T37 DI status The input will go high whenever T37 has 0V and will go low whenever T37 has 24V
[21] Thermal warning The thermal warning turns on when the temperature exceeds the limit in the motor, the frequency
converter, the brake resistor, or the thermistor..
[30] Brake fault (IGBT) Will go high when the brake IGBT is short-circuited.
[40] Out of ref range If Comparator 0 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[60] Comparator 0 If Comparator 0 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[61] Comparator 1 If Comparator 1 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[62] Comparator 2 If Comparator 2 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[63] Comparator 3 If Comparator 3 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[64] Comparator 4 If Comparator 4 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[65] Comparator 5 If Comparator 5 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[70] Logic Rule 0 If Logic Rule 0 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[71] Logic Rule 1 If Logic Rule 1 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[72] Logic Rule 2 If Logic Rule 2 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
[73] Logic Rule 3 If Logic Rule 3 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
104
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
