5-32 Term X30/6 Digi Out (MCB 101)
This parameter is active when option module MCB 101 is mounted in the frequency converter. Same options and functions as par. 5-3*.
Option: Function:
[0] * No operation
5-33 Term X30/7 Digi Out (MCB 101)
This parameter is active when option module MCB 101 is mounted in the frequency converter. Same options and functions as par. 5-3*.
Option: Function:
[0] * No operation
3.7.5 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
5-40 Function Relay
Array [8]
(Relay 1 [0], Relay 2 [1]
Option MCB 105: Relay 7 [6], Relay 8 [7] and Relay 9 [8]).
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
Option: Function:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Standby / no warning
[5] * Running Default setting for relay 2.
[6] Running / no warning
[8] Run on ref/no warn
[9] * Alarm Default setting for relay 1.
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[35] External Interlock
[36] Control word bit 11
3 Parameter Description VLT
®
HVAC Drive Programming Guide
86
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
