26-27 Term. X42/3 Live Zero
Option: Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input
is a part of the frequency converter control, rather than being used as part of a decentral I/O system,
such as a Building Management System.
[0] Disabled
[1] * Enabled
3.24.5 26-3* Analog Input X42/5
Parameters for configuring the scaling and limits for analog input, terminal X42/5.
26-30 Terminal X42/5 Low Voltage
Range: Function:
0.07 V* [Application dependant] Enter the low voltage value. This analog input scaling value should correspond to the low reference/
feedback value set in par. 26-34
Term. X42/5 Low Ref./Feedb. Value .
26-31 Terminal X42/5 High Voltage
Range: Function:
10.00 V* [Application dependant] Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 26-35
Term. X42/5 High Ref./Feedb. Value .
26-34 Term. X42/5 Low Ref./Feedb. Value
Range: Function:
0.000 N/A* [-999999.999 - 999999.999 N/A] Enter the analog input scaling value that corresponds to the low voltage value set in
par. 26-30
Terminal X42/5 Low Voltage .
26-35 Term. X42/5 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Enter the analog input scaling value that corresponds to the high voltage value set in
par. 26-21
Terminal X42/3 High Voltage .
26-36 Term. X42/5 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
noise in terminal X42/5. A high time constant value improves dampening but also increases the time
delay through the filter. This parameter cannot be adjusted while the motor is running.
26-37 Term. X42/5 Live Zero
Option: Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input
is a part of the frequency converter control, rather than being used as part of a decentral I/O system,
such as a Building Management System.
[0] Disabled
[1] * Enabled
3.24.6 26-4* Analog Out X42/7
Parameters for configuring the scaling and output function for analog output, terminal X42/7.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
258 MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
