3.15.5 15-3* Alarm Log
Parameters in this group are array parameters, where up to 10 fault logs can be viewed. [0] is the most recent logged data, and [9] the oldest. Error
codes, values, and time stamp can be viewed for all logged data.
15-30 Alarm Log: Error Code
Array [10]
Range: Function:
0 N/A* [0 - 255 N/A] View the error code and look up its meaning in the
Troubleshooting
chapter.
15-31 Alarm Log: Value
Array [10]
Range: Function:
0 N/A* [-32767 - 32767 N/A] View an extra description of the error. This parameter is mostly used in combination with alarm 38
‘internal fault’.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s* [0 - 2147483647 s] View the time when the logged event occurred. Time is measured in seconds from frequency con-
verter start-up.
15-33 Alarm Log: Date and Time
Range: Function:
Application
dependent*
[Application dependant] Array parameter; Date & Time 0 - 9: This parameter shows at which time the logged event occurred.
3.15.6 15-4* Drive Identification
Parameters containing read only information about the hardware and software configuration of the frequency converter.
15-40 FC Type
Range: Function:
0 N/A* [0 - 0 N/A] View the FC type. The read-out is identical to the frequency converter series power field of the type
code definition, characters 1-6.
15-41 Power Section
Range: Function:
0 N/A* [0 - 0 N/A] View the FC type. The read-out is identical to the frequency converter series power field of the type
code definition, characters 7-10.
15-42 Voltage
Range: Function:
0 N/A* [0 - 0 N/A] View the FC type. The read-out is identical to the frequency converter series power field of the type
code definition, characters 11-12.
15-43 Software Version
Range: Function:
0 N/A* [0 - 0 N/A] View the combined SW version (or ‘package version’) consisting of power SW and control SW.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
160
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
