[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to the SLC event. Actions are executed when the corresponding
event (defined in par. 13-51
SL Controller Event
) is evaluated as true. The following actions are
available for selection:
[0] * Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up (par. 0-10
Active Set-up
) to ‘1’.
[3] Select set-up 2 Changes the active set-up (par. 0-10
Active Set-up
) to ‘2’.
[4] Select set-up 3 Changes the active set-up (par. 0-10
Active Set-up
) to ‘3’.
[5] Select set-up 4 Changes the active set-up (par. 0-10
Active Set-up
) to ‘4’. If the set-up is changed, it will merge
with other set-up commands coming from either the digital inputs or via a fieldbus.
[10] Select preset ref 0 Selects preset reference 0.
[11] Select preset ref 1 Selects preset reference 1.
[12] Select preset ref 2 Selects preset reference 2.
[13] Select preset ref 3 Selects preset reference 3.
[14] Select preset ref 4 Selects preset reference 4.
[15] Select preset ref 5 Selects preset reference 5.
[16] Select preset ref 6 Selects preset reference 6.
[17] Select preset ref 7 Selects preset reference 7. If the active preset reference is changed, it will merge with other preset
reference commands coming from either the digital inputs or via a fieldbus.
[18] Select ramp 1 Selects ramp 1
[19] Select ramp 2 Selects ramp 2
[22] Run Issues a start command to the frequency converter.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
144
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
