[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-17 Reference 3 Source
Option: Function:
Select the reference input to be used for the third reference signal. par. 3-15 Reference 1 Source ,
par. 3-16
Reference 2 Source and par. 3-17 Reference 3 Source define up to three different refer-
ence signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-19 Jog Speed [RPM]
Range: Function:
Application
dependent*
[Application dependant] Enter a value for the jog speed n
JOG
, which is a fixed output speed. The frequency converter runs
at this speed when the jog function is activated. The maximum limit is defined in par. .
See also par. 3-80
Jog Ramp Time .
3.5.3 3-4* Ramp 1
Configure the ramp parameter, ramping times, for each of the two ramps (par. 3-4* and par. 3-5*).
3 Parameter Description VLT
®
HVAC Drive Programming Guide
66 MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3
