[42] Auto Reset Trip This event is TRUE if the frequency converter is tripped (but not trip-locked) and an Automatic Reset
is issued.
[43] OK Key This event is TRUE if the OK key on the LCP is pressed.
[44] Reset Key This event is TRUE if the Reset key on the LCP is pressed.
[45] Left Key This event is TRUE if the Left key on the LCP is pressed.
[46] Right Key This event is TRUE if the Right key on the LCP is pressed.
[47] Up Key This event is TRUE if the Up key on the LCP is pressed.
[48] Down Key This event is TRUE if the Down key on the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the logic rule.
[51] Comparator 5 Use the result of comparator 5 in the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic rule.
13-02 Stop Event
Option: Function:
Select the boolean (TRUE or FALSE) input to deactivate Smart Logic Control.
[0] False Enters the fixed value of FALSE in the logic rule.
[1] True Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
[3] In range See parameter group 5-3* for further description.
[4] On reference See parameter group 5-3* for further description.
[5] Torque limit See parameter group 5-3* for further description.
[6] Current limit See parameter group 5-3* for further description.
[7] Out of current range See parameter group 5-3* for further description.
[8] Below I low See parameter group 5-3* for further description.
[9] Above I high See parameter group 5-3* for further description.
[10] Out of speed range
[11] Below speed low See parameter group 5-3* for further description.
[12] Above speed high See parameter group 5-3* for further description.
[13] Out of feedb. range See parameter group 5-3* for further description.
[14] Below feedb. low See parameter group 5-3* for further description.
[15] Above feedb. high See parameter group 5-3* for further description.
[16] Thermal warning See parameter group 5-3* for further description.
[17] Mains out of range See parameter group 5-3* for further description.
[18] Reversing See parameter group 5-3* for further description.
[19] Warning See parameter group 5-3* for further description.
[20] Alarm (trip) See parameter group 5-3* for further description.
[21] Alarm (trip lock) See parameter group 5-3* for further description.
[22] Comparator 0 Use the result of comparator 0 in the logic rule.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
133
3
