Danfoss VLT Programming Guide

18-34 Analog Out X42/9 [V]
Range: Function:
0.000 N/A* [0.000 - 30.000 N/A] Read out of the value of the signal applied to terminal X42/9 on the Analog I/O Card.
The value shown reflects the selection in par. 26-50
Terminal X42/9 Output .
18-35 Analog Out X42/11 [V]
Range: Function:
0.000 N/A* [0.000 - 30.000 N/A] Read out of the value of the signal applied to terminal X42/11 on the Analog I/O Card.
The value shown reflects the selection in par. 26-60
Terminal X42/11 Output .
3.17.4 18-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
NB!
Sensorless Readout requires set up by MCT10 with sensorless specific plug in.
18-50 Sensorless Readout [unit]
Range: Function:
0.000 Sen-
sorlessU-
nit*
[-999999.999 - 999999.999 Sen-
sorlessUnit]
3 Parameter Description VLT
®
HVAC Drive Programming Guide
174 MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
