Interface Selection Setup
Product Reference Guide
9
Interface Selection
Upon completing the physical connection between the reader and its host, proceed directly to
"Configuring the Interface" on page 9
for information and programming for the interface type the
reader is connected to (for example: RS-232, Keyboard Wedge, USB, etc.) and scan the
appropriate bar code in tha section to select your system’s correct interface type.
The reader, depending upon the model, will support one of the following sets of host interfaces:
USB Models (3.0 full speed)
•USB-KBD
• USB-COM STD
•USB-OEM
• USB-KBD-ALT
RS-232 / Keyboard Wedge Models
• RS-232 (Standard, Wincor-Nixdorf, OPOS)
• Keyboard Wedge
Wand Interface (TD1130 Pro only)
Configuring the Interface
Scan the programming bar code from the following section which selects the appropriate
interface type matching the system the reader will be connected to. Next, proceed to the
corresponding chapter in this manual (also listed in the table) to configure any desired settings
and features associated with that interface.
NOTE
Unlike some other programming features and options, interface selections
require that you scan only one programming bar code label. DO NOT scan an
ENTER/EXIT bar code prior to scanning an interface selection bar code.
Some interfaces require the reader to start in the disabled state when powered
up. If additional reader configuration is desired while in this state, pull the trig-
ger and hold it for five seconds. The reader will change to a state that allows
programming with bar codes.
