Standard 2 of 5 Enter/Exit Programming Mode
Product Reference Guide 203
Standard 2 of 5 Character Correlation
When correlation is enabled, the bar code reader will combine label data from multiple scans
when decoding. Enabling correlation will help the reader read labels that have some spots and/
or voids. It may also help read labels that have damaged areas. Enabling correlation will also
increase the chances that a label will be read incorrectly.
Standard 2 of 5 Stitching
This option enables/disables stitching for Standard 2 of 5 labels. When parts of a Standard 2 of
5 bar code are presented to the reader with this feature enabled, the bar code parts will be
assembled by the reader’s software, and the data will be decoded if all bar code proofing
requirements are met.
$CS2CO00
Standard 2 of 5 Character Correlation = Disable
$CS2CO01

Standard 2 of 5 Character Correlation = Enable
DEFAULT
NOTE
This feature is available only on the TD1130 model.
$CS2ST00
Standard 2 of 5 Stitching = Disable
$CS2ST01

Standard 2 of 5 Stitching = Enable
DEFAULT

Datalogic Touch 90 pro Specifications

General

Scan speed	256 sec/page
Decoding standards	2/5 family, Code 39, Code 32, Code CIP 39, Code 128, EAN128, EAN/UPC, ISBN/ISSN, CODABAR, Code 93, ISBT128, MSI, Plessey, Telepen, Delta IBM, Code 11, Code 49, Code 16K, GS1 Databar
Standard interfaces	USB, RS-232
Input voltage	5 V
Power consumption	150 mA
Dimensions (WxDxH)	175 x 100 x 80 mm

Weight and Dimensions

Weight	195 g
