Datalogic Touch 90 pro User Manual

Product Reference Guide 281
Appendix A
Technical Specifications
The table below contains Physical and Performance Characteristics, User Environment
and Regulatory information. Table 25 provides Standard Cable Pinouts.
Table 23.
Item Description
Physical Characteristics
Dimensions
Touch 65: 16.0 x 8.4 x 5.8 cm / 6.3 x 3.3 x 2.3 in

Touch 90: 17.0 x 10.4 x 6.7 cm / 6.7 x 4.1 x 2.7 in
Weight (without cable)
Touch 65: 130.0 g / 4.6 oz

Touch 90: 153.0 g / 5.4 oz
Color
Black; TD1130 (Pro) available in White ;

Other colors and custom logo options are available for minimum
quantity purchase.
Electrical Characteristics
Voltage & Current
Operating (Typical): < 100 mA @ 5 VDC

Standby/Idle (Typical): 20 mA @ 5 VDC 
Max 180mA @ 5VDC
Input Voltage 5 VDC +/- 0.5 V
Reading Performance
Imager Sensor Linear Imaging Sensor: Illumination: Red LED 640 nm wavelength
Print Contrast Ratio (Minimum) 25%
Roll (Tilt) Tolerance ± 45° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 70°
Reading Indicators Beeper (Adjustable Tone); Good Read LED
Resolution

(1D Codes, Maximum)
Touch 65 Minimum Resolution = 4 mil (0.102 mm)

Touch 90 Min Resolution = 5 mil (0.127 mm)
Technical Specifications

Datalogic Touch 90 pro Specifications

General

Scan speed	256 sec/page
Decoding standards	2/5 family, Code 39, Code 32, Code CIP 39, Code 128, EAN128, EAN/UPC, ISBN/ISSN, CODABAR, Code 93, ISBT128, MSI, Plessey, Telepen, Delta IBM, Code 11, Code 49, Code 16K, GS1 Databar
Standard interfaces	USB, RS-232
Input voltage	5 V
Power consumption	150 mA
Dimensions (WxDxH)	175 x 100 x 80 mm

Weight and Dimensions

Weight	195 g
