Specifies a mid-label ID that is added for transmission between the labels of a two label pair.
The expected string is a maximum of 20 characters. When combining two label pairs into a
single label for transmission to the host, this label ID can be added to the data, following the
first label and preceding the second label.
1. Scan the ENTER/EXIT bar code.
2. Scan the bar code in
"Set Global Mid Label ID Character(s)" on page 64
3. Determine the desired character(s) (you may choose up to twenty) which will represent
the Mid Label ID for two label pairs. If the first character is 00, then nothing is added
between the two labels.
4. Turn to the
ASCII Chart
on the inside back cover of this manual and find the equivalent hex
digits associated with your choice of Label ID. For ex
ample, if you wish to select the char-
acters ‘M’, ‘I’ and ‘D’ as a Label ID, the chart i
ndicates its associated hex characters as
4D4944. Turn to
Keypad, starting on page 305
and scan the bar codes representing the hex
characters determined. For the example given, the characters ‘4’, ‘D’, ‘4’, ‘9’, ‘4’ and ‘4’
woul
d be scanned. More examples of Label ID settings are provided in
Table 15
.
NOTE
If you make a mistake before the last character, scan the CANCEL bar code
to abort and not save the entry string. You can then start again at the
beginning.
5. The reader will save the string and exit Programming Mode when:
• the ENTER/EXIT bar code is scanned a second time, or
• the hex values for all twenty available characters have
been entered, or
• the first 00 hex value entered terminates the string.
This completes the steps to configure a Global Mid
Label ID for two label pairs.
Character Conversion
Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs
represented in hexadecimal ASCII values. The first character in the pair is the character that will
be converted. The second character in the pair is the character to convert to. If the character to
convert in a pair is FF, then no conversion is done.
For example, if you have the character conversion configuration item set to the following:
41423132FFFFFFFF
The first pair is 4142 or AB (41 hex is an ASCII capital A, 42 hex is an ASCII capital B) and the
second pair is 3132 or 12 (31 hex is an ASCII 1, 32 is an ASCII 2). The other two pairs are
FFFF and FFFF.
With the label, AB12BA21, it would look as follows after the character
conversion: BB22BB22.
