Datalogic Touch 90 pro User Manual

Data Format References
Product Reference Guide 269
Label ID: Set Individually Per Symbology — continued
Table 15
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT bar code
(Reader enters Programming Mode)
2.
Determine placement of the
Label ID char
acters BEFORE or
AFTER with regard to scanned
data using
"Label ID Control" on
page 57
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the bar code selecting
the sym
bology type you wish
to designate label ID
characters for using
Label ID
Symbology Selection, starting on
page 58
.
GS1 DataBar
Omnidirectional
Code 39
Interleaved 2 of
5
Code 32
4.
Custom Label ID example
(desired characters):
D B * = C 3 + P H
5.
Find hex equivalents from the
ASCII table (
inside back cover),
then scan in these digits/
characters using the bar codes
in the section:
Keypad, starting
on page 305
. f you make a
mistake before the last
character, scan the CANCEL
bar code to abort and not save
the entry string. You can then
start again at the beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan the ENTER/EXIT bar code
(Reader exits Label ID entry)
7.
Scan the ENTER/EXIT bar code
once again
(Reader exits Programming Mode)
Result:
DB*[bar code
data]
[bar code
data]=C3
+[bar code
data]
[bar code data]PH
. Label ID Examples

Datalogic Touch 90 pro Specifications

General

Scan speed	256 sec/page
Decoding standards	2/5 family, Code 39, Code 32, Code CIP 39, Code 128, EAN128, EAN/UPC, ISBN/ISSN, CODABAR, Code 93, ISBT128, MSI, Plessey, Telepen, Delta IBM, Code 11, Code 49, Code 16K, GS1 Databar
Standard interfaces	USB, RS-232
Input voltage	5 V
Power consumption	150 mA
Dimensions (WxDxH)	175 x 100 x 80 mm

Weight and Dimensions

Weight	195 g
