In order for this function to work, menu 6295 Idle active must be enabled, and the relay output must be configured. Otherwise the
low speed function will not work.
6.3.5 Inhibit
The alarms that are deactivated by the inhibit function are inhibited in the usual manner, except for the oil pressure alarms; RMI oil
102, 105 and 108 which are active during "idle run" as well.
6.3.6 Running signal
The running feedback must be activated when the genset is running in idle mode.
INFO
The running detection level (parameter 6173) must be below the idle speed. See Start-up overview with idle run.
6.3.7 Idle speed flowcharts
The flowcharts illustrate the starting and stopping of the genset by use of the inputs "temp control" and "low speed".
DESIGNER'S HANDBOOK 4189341275A EN Page 108 of 196
