P measurement from a transducer
Text Parameter Default Range Description
Transducer Range 7261 0 kW 0 to 20000 kW* Maximum active power
Transducer Range 7262 0 kW -20000 to 0 kW* Minimum active power
Mains P measure 7263 Multi input 102
Multi input 102 (transducer)
CIO308 1.14 (transducer)
Selection of the analogue input
*Note: Scaling (parameter 9030) affects this range. The range shown is based on a scaling of 100V-25000V.
INFO
As soon as transducer max. or min. settings are changed to a value different from 0, the controller will use the transducer
signal.
More information
The information above is for a mains power measurement for a genset controller. For a mains controller, see Mains
functions, Mains power measurement in Option G5 Power management.
2.4.13 Mains reactive power or voltage transducer
It is also possible to use transducers to measure mains voltage or reactive power. To set-up these transducers use menu 7270
(Mains reactive power) and 7280 (Mains voltage).
To be compliant with national grid codes it is often necessary to measure in the grid connection point. Using transducers are the
practical solution in case of long distance. See documentation for option A10 for more information.
Q measurement from a transducer
Text
Parameter Default Range Description
Transducer Range 7271 0 kvar -20000 to 20000 kvar* Maximum reactive power
Transducer Range 7272 0 kvar -20000 to 20000 kvar* Minimum reactive power
Mains Q measure 7273 Multi input 102
Multi input 102 (transducer)
CIO308 1.17 (transducer)
Selection of the analogue input
*Note: Scaling (parameter 9030) affects this range. The range shown is based on a scaling of 100V-25000V.
Set up the input for 4-20 mA, and define the range of the transducer in parameter 7271 and 7272. The range is defined with a min.
and max. setting where the min. setting corresponds to 4 mA and the max. setting to 20 mA.
U measurement from a transducer
Text
Parameter Default Range Description
Transducer Range 7281 0 V 0 to 25000 V* Maximum voltage
Transducer Range 7282 0 V 0 to 25000 V* Minimum voltage
Mains U measure 7283 Multi input 102
Multi input 102 (transducer)
CIO308 1.20 (transducer)
Selection of the analogue input
Mains U Ext Nom 7284 400 V 100 to 25000 V* Nominal grid voltage for the transducer
*Note: Scaling (parameter 9030) affects this range. The range shown is based on a scaling of 100V-25000V.
Set up the input for 4-20 mA, and define the range of the transducer in parameter 7281 and 7282. The range is defined with a min.
and max. setting where the min. setting corresponds to 4 mA and the max. setting to 20 mA.
DESIGNER'S HANDBOOK 4189341275A EN Page 26 of 196
