1. Introduction

1.1 About the Designer's Handbook

1.1.1 General purpose

This Designer's Handbook provides overall information about the controller applications and functions. This document also

provides the information needed to configure the application and its parameters.

See the Installation instructions for installation information. See the Operator's manual for information on how to operate the

controller.

CAUTION

Read this document before starting to work with the controller and the equipment to be controlled. Failure to do this could

result in human injury or damage to the equipment.

1.1.2 Intended users

This Designer's Handbook is mainly intended for the panel builder designer. On the basis of this document and the Installation

instructions, the panel builder designer will give the electrician the information he needs to install the controller, for example, detailed

electrical drawings.

1.1.3 Options

This Designer's Handbook describes the standard AGC-4 Mk II controller.

The controller functions can be increased by a variety of flexible hardware and software options. The options include generator,

busbar and mains protections; voltage/VAr/PF control; various outputs; power management; serial communication; additional

operator display; and more. The Data Sheet includes a complete list of options.

The options are described in detail in Description of Options documents.

1.1.4 Parameter list

The Designer’s Handbook refers to parameters. For further information, see the Parameter list.

1.1.5 Glossary

Term

Abbreviation Explanation

Additional Operator Panel AOP

AGC-4 Mk II AGC-4 Mk II

By default, a genset controller. With option G5, also a mains or BTB controller.

With option G7, also a group or plant controller. AGC-4 Mk II is based on

AGC-4, with updated hardware.

Automatic Load Controller ALC-4

Automatic Mains Failure AMF

If there is a mains failure, the AGC automatically uses a genset to supply the

load.

Automatic Sustainable Controller ASC-4

Automatic transfer switch ATS

Automatic voltage regulator AVR

Busbar BB

Bus tie breaker BTB

DESIGNER'S HANDBOOK 4189341275A EN Page 8 of 196
