6.36.2 Stop swbd error (menu 6510)
When activated, this function will stop the genset if the genset is running in Auto mode.
Set points available:
• Delay: When the input is active and the delay has expired, the genset will trip the breaker, cool down and stop. The function is
active regardless of the "Enable" setting.
• Output A: Relay to activate when the delay has expired.
• Output B: Relay to activate when the delay has expired.
• Enable: Enable/disable the alarm function.
• Fail class: The fail class of the alarm.
6.37 Digital inputs
The controller has a number of digital inputs, some of which are configurable and some are not.
• Engine interface card: M4 (standard).
• Available digital inputs – not configurable: 1
• Available digital inputs – configurable: 6
Input function
Auto Semi Test Man Block DG Mains BTB Input type
1 Shutdown override X X X X X X X Constant
2 Remote start X X X Pulse
3 Remote stop X X X Pulse
4 Semi-auto X X X X X X X Pulse
5 Test X X X X X X Pulse
6 Auto X X X X X X X Pulse
7 Manual X X X X Constant
8 Block X X X X X X X Constant
9 Remote GB/TB/BTB ON X X X X X Pulse
10 Remote GB/TB/BTB OFF X X X X X Pulse
11 Remote MB ON X X X X X Pulse
12 Remote MB OFF X X X X X Pulse
13
Remote alarm
acknowledge
X X X X X X X X Constant
14 Auto start/stop X X X Constant
15 Mains OK X X X X X X X Pulse
16 External f control X X X X Constant
17 External P control X X X X X Constant
18 External U control X X X X Constant
19 External cos phi control X X X X Constant
20 External var control X X X X Constant
21 Remove starter X X X X X Constant
22
Reset analogue GOV/AVR
outputs
X X X X X X Pulse
23 Manual GOV up X X X X X Constant
