6.23 Alarm inhibit
In order to select when the alarms are to be active, a configurable inhibit setting for each alarm has been made. The inhibit
functionality is only available via the PC utility software. For each alarm, there is a drop-down window where it is possible to select
which signals that have to be present in order to inhibit the alarm.
Selections for alarm inhibit:
Function
Description
Inhibit 1
M-Logic outputs: Conditions are programmed in M-Logic
Inhibit 2
Inhibit 3
GB on (TB on) The generator breaker is closed
GB off (TB off) The generator breaker is open
Run status Running detected and the timer in menu 6160 expired
Not run status Running not detected or the timer in menu 6160 not expired
DESIGNER'S HANDBOOK 4189341275A EN Page 145 of 196
